ZB4BZ079
Body fixing collar, Harmony XB4, metal fixing collar pillar for printed circuit board
This Harmony XB4, body/fixing collar allows to connect together XB4 heads with printed circuit board. It is made of metal and is compatible with Harmony XB4. It has a metal bezel, this makes it Ideal for severe environments, especially applications requiring high impact and vibration resistance. It is designed to fit with a standard 22mm control and signaling units, ensuring compatibility when installing in pre-existing machinery.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Rohs Exemption Information | Yes |
|---|---|
| Mercury Free | Yes |
| Toxic Heavy Metal Free | Yes |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| China Rohs Regulation | X |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Country of Origin | United States |
| Weight | 0.003 kg |
| Range Of Product | Harmony XB4 |
| Accessory / Separate Part Designation | fixing collar |
| Accessory / Separate Part Category | mounting and fixing accessories |
| Product Or Component Type | body fixing collar |
| Material | metal |
| Accessory / Separate Part Type | body fixing collar |
| Accessory / Separate Part Destination | printed circuit board support |
| Net Weight | 0.003 kg |
| Additional Information | must be used in conjunction with adaptor ZBZ010 |
| Quantity Per Set | set of 10 |
| Warranty | 18 months |
