ZARC703
Harmony eXLhoist, compact, Battery table charger 5 V DC
Specifications
| Country of Origin | United States |
|---|---|
| Weight | 0.12 kg |
| Range Of Product | Harmony eXLhoist |
| Accessory / Separate Part Category | electrical accessory |
| Accessory / Separate Part Type | battery charger |
| China Rohs Regulation | X |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Ambient Air Temperature For Operation | 0-40 °C |
| Ambient Air Temperature For Storage | -20-60 °C |
| Nominal Output Current | 1.2 A 5 V DC |
| [Us] Rated Supply Voltage | 5 V DC |
| Connections - Terminals | 5-position plug-in connector |
| Net Weight | 0.12 kg |
Documents
- ZARC702 - ZARC703 Battery Table Charger, Instruction Sheet - PHA1791802_01 (pdf)
- ZARC701 Multi charger power supply, Instruction Sheet - PHA1791702_01 (pdf)
- ZART8LS / ZARB10WS. Transmitter (8 pushbuttons) and Receiver small size, Instruction Sheet - PHA1791602_01 (pdf)
- Spec Sheet
- Catalog Harmony eXLhoist - Wireless industrial radio remote control English 04/2021 - Catalog+Harmony+eXLhoist+-+Wireless+industrial+radio+remote+control (pdf)
- Digest Catalog 19: Push Buttons and Operator Interface (MAY 2019) - 0100CT1901_SEC-19 (pdf)
- Push Buttons: Section 19 - Digest 179 (2024) - Push-Buttons-Digest-Catalog-0100CT2401-SEC-19 (pdf)
