XBTZ9782 - Uni-Telway/Modbus serial link - L = 10 m - 1 male mini DIN 1 RJ45

XBTZ9782

Uni-Telway/Modbus serial link - L = 10 m - 1 male mini DIN + 1 RJ45

This Magelis XBTZ is a RS 485 cable for Modbus/Uni-TE serial link. It is equipped with one 8-way female mini-DIN connector at one end and one 25-way male SUB-D connector at the other end. it is 10 meters long. It enables direct connection between Magelis XBT terminals and PLCs.

Brand: Schneider Electric

Add to Quote Catalogue

Specifications

Rohs Exemption Information	Yes
Mercury Free	Yes
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
California Proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Weee	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation	X
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
Country of Origin	China
Length	10 m
Range Of Product	Harmony XBT
Accessory / Separate Part Designation	Uni-Telway/Modbus serial link
Cable Length	10 m
Accessory / Separate Part Category	connection accessories
Accessory / Separate Part Type	connecting cable
Accessory / Separate Part Destination	XBT terminal small touch screen panel
Electrical Connection	1 male connector mini DIN, 8 pins 1 male connector RJ45
Communication Port Protocol	Uni-Telway Modbus
Physical Interface	RS485
Range Compatibility	Modicon Premium automation platform Modicon TSX Micro Twido Harmony STO & STU Harmony HMI GTO
Product Compatibility	XBTR400 XBTRT500 XBTRT511 XBTGT2... XBTN400 XBTN200 XBTGK....
Warranty	18 months

Uni-Telway/Modbus serial link - L = 10 m - 1 male mini DIN + 1 RJ45
