VW3A3620
speed monitoring module, Altivar, 5V
Specifications
| Rohs Exemption Information | Yes |
|---|---|
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP2010018EN |
| Sustainable Offer Status | Green Premium product |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| China Rohs Regulation | X |
| Circularity Profile | N/A |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Country of Origin | Indonesia |
| Weight | 0.3 kg |
| Number Of Pulses Per Revolution | 3600 ATV32 |
| Range Of Product | Altivar |
| Product Or Component Type | encoder interface module |
| Range Compatibility |
|
| [Us] Rated Supply Voltage | 5 V 5-5.5 V) |
| Electrical Connection | terminal 1.5 mm² AWG 16), encoder, 200 mA |
| Net Weight | 0.3 kg |
| Product Compatibility | ATV32 >= V1.8) |
| Protection Type |
|
| Input Signal | TTL |
| Maximum Operating Frequency | 250 kHz |
