OEM assembler kit, Surgelogic, 120kA, 208Y/120 VAC, 3 phase, 4 wire, SPD type 2
Square D™ load center surge protective devices, TVS2IMA12O, are easy to install plug-in units that install as quickly as a standard circuit breaker. The surge suppressors use two pole spaces in a QO™ or Homeline™ load center, or NQ panelboard. US and Canadian UL® Listed as Type 2 SPD to the UL 1449 standard. Complies with requirements of NEC® Article 285, CSA 233.1-87, and CSA C22.2 No. 8- M1986 as appropriate. This device provides 80 kA of short circuit protection and 80 kA of surge protection per phase and comes in consumer package. The surge protection device is in a NEMA 1 house. The surge protection device is service entrance mounted. The surge protection device is CSA certifed by UL.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Standards |
|
|---|---|
| Nema Degree Of Protection | NEMA 2 |
| Warranty | 18 months |
| Rohs Exemption Information | Yes |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Eu Rohs Directive | Compliant with Exemptions |
| Height | 155.7 mm |
| Connections - Terminals | lugs AWG 12...AWG 2 aluminium/copper 4 N.m |
| Provided Equipment |
|
| Surge Current | 120 kA per phase |
| Nominal Discharge Current | 20 kA |
| Phase | 3 phase |
| Short-Circuit Protection | 200 kA |
| [Uc] Maximum Continuous Operating Voltage | 150 V |
| Width | 250.4 mm |
| Wiring Configuration | 4-wire |
| Depth | 92.7 mm |
| [Ue] Rated Operational Voltage | 208Y/120 V AC |
| Country of Origin | China |
| Width | 250.4 mm |
| Height | 155.7 mm |
| Range Of Product | Surgelogic |
| Product Or Component Type | surge protection device |
| Device Short Name | IMA |
