Expansion module, Modicon M171/M172/M173, performance, 27 IO
This product is part of the Modicon M171/M172 range, an offer I/O modules for HVAC solutions. This additional I/O module offers 8 discrete inputs with sink or source (positive/negative) discrete input logic. It is a module with discrete input voltage ranges from 24V AC/DC to 48V DC and analogue output voltage ranges from 0V to 15V. This module offers 3 SPST relay output, 2 SPST relay output with same common and 2 SPDT relay output with independent common discrete output. It is an IP20 rated product. Its dimensions are 140mm (width) x 61.6mm (depth) x 110mm (height). It weighs 0.19kg. The main application of this module is HVAC and pumping solution. Modicon M171/M172 benefits maximize profitability and energy efficiency by using scalable automation control with the Modicon M171/M172. Modicon M171/M172 logic controllers and intuitive software EcoStruxure Machine Expert - HVAC are designed for maximizing profitability and energy efficiency.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Country of Origin | Italy |
|---|---|
| Width | 140 mm |
| Height | 110 mm |
| Weight | 0.19 kg |
| Analogue Output Number |
|
| Range Of Product | Modicon M171/M172 |
| Discrete Output Number |
|
| Product Or Component Type | additional I/O module |
| Number Of Inputs/Outputs | 27 |
| Discrete Output Current |
|
| Analogue Input Number |
|
| Discrete Input Number | 8 |
| Product Specific Application | HVAC and pumping solution |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1710005EN |
| Sustainable Offer Status | Green Premium product |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI1710005EN |
| Upgradeability | Upgradeable through digital modules and upgraded components |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Height | 110 mm |
| Mounting Support | DIN rail |
| Discrete Input Voltage |
|
| Display Type | Without Display |
| Net Weight | 0.19 kg |
| Number Of Port | 1 CAN port - screw terminal block |
| [Us] Rated Supply Voltage |
|
| Sensor Power Supply |
|
| Input Impedance | 20 kOhm |
| Discrete Input Current | 2.5 mA |
| Realtime Clock | without clock at -20-55 °C |
| Width | 140 mm |
| Analogue Input Type |
|
| Overvoltage Category | II |
| Depth | 61.6 mm |
| Input/Output Number |
|
| Discrete Input Logic | sink or source (positive/negative) |
| Product Certifications |
|
| Standards | EN/IEC 60730 |
| Pollution Degree | 2 |
| Ambient Air Temperature For Operation | -20-55 °C UL 60730-1 |
| Directives |
|
| Ambient Air Temperature For Storage | -40-85 °C |
| Relative Humidity | 10-90 % non-condensing |
| Ip Degree Of Protection | IP20 |
