S48901
Lifting device kit, MasterPacT NW, crossbar for MTZ3 circuit breaker or cradle
Square D PowerPact P, M and R-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits Molded case circuit breakers are available with either basic electronic trip system or Micrologic electronic trip units. This is a lifting device kit, Crossbar for MasterPacT Y-frame circuit breaker or cradle
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Eu Rohs Directive | Not applicable, out of EU RoHS legal scope |
|---|---|
| California Proposition 65 | WARNING: This product can expose you to chemicals including: DINP and DIDP which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov |
| Country of Origin | United States |
| Range Of Product | MasterPact NW |
| Circuit Breaker Type | Y-frame |
| Accessory / Separate Part Category | lifting accessory |
| Product Or Component Type | lifting bar |
| Warranty | 18 months |
Documents
- MasterPacT NT IEC Low-Voltage Power Circuit Breaker - User Guide - 0613IB1210_tri+net (pdf)
- ArcBlok Prepared Space Cassette (PSC) for MasterPacT MTZ2, MTZ3, NW Circuit Breakers, Installation Instructions - HRB23948_05 (pdf)
- MasterPacT NW IEC 60947-2 DC Circuit Breaker Installation Instructions - HRB39254 (pdf)
- MasterPacT NW Low-Voltage Power/Insulated Case Circuit Breaker Installation Instructions - 0613IB1203_Tri+net (pdf)
- MasterPacT NW Low-Voltage Power/Insulated Case Circuit Breaker with ArcBlok Technology - Installation - HRB23946_Tri+net (pdf)
- MasterPacT NW 1000-4000 A DC Circuit Breaker - User Guide - 0613IB1211_Tri+net (pdf)
- MasterPacT NW 1000-4000 A DC Circuit Breaker Installation Instructions - HRB39255_tri+net (pdf)
- MasterPacT NW Low-voltage Power/Insulated Case Circuit Breaker Installation Instructions - 0613IB1204_Tri+net (pdf)
- MasterPacT NW Low-Voltage Power/Insulated Case Circuit Breaker Installation Instructions - HRB78505_Tri+net (pdf)
- Cost-Effective Switchgear Modernization Brochure - 998-19819263_GMA-US_Modernization+Brochure (pdf)
- EcoStruxure Power Asset Performance eGuide - 998-20406243_US_NEMA (pdf)
- MasterPacT MTZ Circuit Breakers Brochure - Are+You+Future+Ready+-+Masterpact+MTZ+Circuit+Breakers+brochure (pdf)
- Spec Sheet
- Digest Catalog 07: Miniature and Molded Case Circuit Breakers - SE-Digest-07-Circuit-Breakers (pdf)
