S33930
Circuit breaker accessory, PowerPacT P, I-Line, HCR-U, bolt on, sub feed lugs, 1200A, 3/0 to 600kcmil
Square D sub-feed lug kits are UL Listed for use on Listed equipment. They have plug-on jaw construction and plug on to the I-Line bus stack in the same manner as branch circuit breakers. Lugs on these devices accommodate the same wire sizes as the equivalent ampere rated circuit breakers. This I-line sub-feed lug kit is 3 pole with 1200A current rating and is used for I-line, HCR-U panels with I-line circuit breakers. Mounting height is 15 inches and terminal data is 4 wires of AWG 3/0 - 600 kcmil. There are 4 conducters per lug.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Product Certifications |
|
|---|---|
| Warranty | 18 months |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Circularity Profile | ENVEOLI1407013EN |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1407013EN |
| Sustainable Offer Status | Green Premium product |
| Pvc Free | Yes |
| Eu Rohs Directive | Compliant with Exemptions |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Halogen Content Performance | Halogen free plastic parts product |
| Product Destination |
|
| Line Rated Current | 1200-1200 A |
| Bar Length | 381 mm |
| Awg Gauge | AWG 3/0...600 kcmil |
| Country of Origin | United States |
| Length | 381 mm |
| Range Of Product |
|
| Product Or Component Type | sub-feed lug |
