QOU3807100 - Mini circuit breaker, QOU, 80A, 3 pole, 240 VAC, 10kA, lock-off

QOU3807100

Add to Quote Catalogue

Product Certifications	IEC UL Listed CSA
Warranty	18 months
Rohs Exemption Information	Yes
Mercury Free	Yes
Sustainable Offer Status	Green Premium product
California Proposition 65	WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
China Rohs Regulation	Product out of China RoHS scope. Substance declaration for your information.
Circularity Profile	N/A
Eu Rohs Directive	Compliant with Exemptions
Halogen Content Performance	Halogen free product
Height	4.45 in
Tightening Torque	45-45 lbf.in (AWG 12...AWG 2/0)
Electrical Connection	slotted box lugs, line side slotted box lugs, load side
Mounting Mode	unit mount
Line Rated Current	80 A
Awg Gauge	AWG 12...AWG 2/0 aluminium/copper
Width	2.25 in
Depth	2.95 in
[Ue] Rated Operational Voltage	120/240 V AC 240 V AC 120 V AC 60 V DC
Country of Origin	United States
Width	2.25 in
Height	4.45 in
Range Of Product	QOU
Circuit Breaker Type	standard
Product Or Component Type	miniature circuit-breaker
Circuit Breaker Application	HACR rated
