Mini circuit breaker, QO, 20A, 1 pole, 120VAC, 22kA, bolt on, combo ARC fault, pigtail, fungal treatment
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 20A at 120VAC. This unit provides 22kA breaking capacity and bolt on mounting. This product includes a combination arc fault with pigtail, and fungal treatment. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Product Certifications |
|
|---|---|
| Ambient Air Temperature For Operation | 40 °C |
| Warranty | 18 months |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Eu Rohs Directive | Under investigation |
| Height | 121 mm |
| Tightening Torque | 4.6-4.6 N.m |
| Number Of Spaces Required | 1 |
| Net Weight | 0.259 kg |
| Breaking Capacity | 22 kA 120 V AC |
| Awg Gauge |
|
| Width | 19 mm |
| Depth | 74 mm |
| Country of Origin | Mexico |
| Width | 19 mm |
| Height | 121 mm |
| Weight | 0.259 kg |
| Connections - Terminals | pigtail neutral |
| Circuit Breaker Type | combination ARC-fault |
| Range Of Product | QO |
| Product Or Component Type | miniature circuit-breaker |
| Circuit Breaker Application | HACR rated |
| Mounting Mode | bolt-on |
| Poles Description | 1P |
| Electrical Connection | pressure plate |
| Line Rated Current | 20 A |
| [Ue] Rated Operational Voltage | 120 V AC |
