Mini circuit breaker, QO, 30A, 1 pole, 120/240VAC, 65kA, bolt on
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 65kA breaking capacity and bolt on mounting. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Product Certifications |
|
|---|---|
| Ambient Air Temperature For Operation | 40 °C |
| Warranty | 18 months |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Sustainable Offer Status | Green Premium product |
| Toxic Heavy Metal Free | Yes |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Circularity Profile | N/A |
| Eu Rohs Directive | Compliant with Exemptions |
| Halogen Content Performance | Halogen free product |
| Height | 76 mm |
| Tightening Torque | 4.6-4.6 N.m |
| Number Of Spaces Required | 1 |
| Net Weight | 0.136 kg |
| Breaking Capacity |
|
| Awg Gauge | AWG 14...AWG 8 copper or aluminium |
| Width | 19 mm |
| Depth | 74 mm |
| Country of Origin | United States |
| Width | 19 mm |
| Height | 76 mm |
| Weight | 0.136 kg |
| Circuit Breaker Type | standard |
| Range Of Product | QO |
| Product Or Component Type | miniature circuit-breaker |
| Circuit Breaker Application | HACR rated |
| Mounting Mode | bolt-on |
| Poles Description | 1P |
| Electrical Connection | pressure plate |
| Line Rated Current | 30 A |
| [Ue] Rated Operational Voltage |
|
