PCSPCT190X1000
AccuSine+ auxiliary transformer - 5/1 - Step-down Transformer to 1 A
Specifications
| Product Certifications |
|
|---|---|
| Weight | 1.8 kg |
| Secondary Current | 1 A |
| Range Compatibility |
|
| Accessory / Separate Part Category | measurement accessory |
| Product Or Component Type | auxiliary transformer |
| Range | AccuSine |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Toxic Heavy Metal Free | Yes |
| Eu Rohs Directive | Compliant |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Network Frequency | 50...400 Hz |
| [Ue] Rated Operational Voltage | 600 V AC 50...400 Hz |
| Mounting Mode | by screws |
| Current Transformer Ratio | 5/1 |
| Electrical Connection | studs2500 V |
| Width |
|
| Height | body: 124 mm |
| Mounting Support | plate |
| Input Impedance | 0.5 Ohm |
| Line Rated Current | 5 A |
| Continuous Thermal Current Rating Factor |
|
| [Uimp] Rated Impulse Withstand Voltage | 10 kV (50 µs) |
| Net Weight | 1.8 kg |
| Depth |
|
