NSYCVF65M115PF
Climasys forced vent. 65 m3/hour, 115V, with outlet grille plastic and filter
Climasys Forced ventilator with outlet grille plastic and filter. 115 V 50/60 Hz input voltage. Free flow rate w/o filter/grille is 170 m3/h. Free flow rate w/ std. filter is 65 m3/h at 50 Hz. ABS for outlet grille, Polyurethane foam for filter. Black color. IP20. Cut-out dimensions 108 mm.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Device Composition |
|
|---|---|
| Depth | external : 55 mm |
| Cut-Out Dimensions | Ø 108 mm |
| Width | external: 124 mm |
| Height | external: 124 mm |
| Material |
|
| Ip Degree Of Protection | IP20 |
| Color |
|
| Country of Origin | France |
| Air Flow |
|
| Type Of Ventilation Filter | standard |
| Product Or Component Type | fan |
| Product Name | ClimaSys CV |
| Range | ClimaSys |
| Input Voltage | 115 V 50/60 Hz |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP110717EN |
| Sustainable Offer Status | Green Premium product |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Circularity Profile | ENVEOLI1107017EN |
| Eu Rohs Directive | Compliant with Exemptions |
| Warranty | 18 months |
Documents
- Climasys - Instruction sheet for outlet Grid and filter Fan - 04432404-T (pdf)
- ClimaSys Thermal Management System Brochure - Climasys.Enclosure-Thermal+Management+Brochure (pdf)
- Spec Sheet
- Spacial, Thalassa, and ClimaSys Universal Enclosures US Catalog 2022 - SE_Enclosure_US_2022_V0 (pdf)
- Spacial, Thalassa, and ClimaSys Universal Enclosures Catalog - 9993CT0901R08_16+Body+(Web) (pdf)
