LUALB1 – Current limiter disconnector, TeSys Ultra, 32A/690V, activation 50kA, Iq 130kA@440V, mounting on power base
LUALB1
Current limiter disconnector, TeSys Ultra, 32A/690V, activation 50kA, Iq 130kA@440V, mounting on power base

TeSys U short circuit current limiter block to be connected in series and upstream of a TeSys U starter controller. It increases the starter controller ability to withstand the short circuit current from 50 kA to 130 kA under 400 V. It includes a limiter cartridge LUALF1. To be mounted directly on the upstream terminals of a power base, it must be connected to one power base only. Green Premium compliant (RoHS/REACh).

Brand: Schneider Electric

Add to Quote Catalogue
Specifications
[Ith] Conventional Free Air Thermal Current 32 A
Net Weight 0.31 kg
Connections - Terminals
  • connector 1 x 1-10 mm² flexible without cable end
  • connector 1 x 1-6 mm² flexible with cable end
  • connector 2 x 1-6 mm² flexible with cable end
  • connector 2 x 1-6 mm² flexible without cable end
  • connector 1 x 1.5-10 mm² solid
  • connector 2 x 1.5-6 mm² solid
Mounting Mode direct
[Ui] Rated Insulation Voltage
  • 690 V EN 60947-1
  • 690 V IEC 60947-1
Activation Threshold 50 kA
Tightening Torque
  • 1.9-2.5 N.m flat Ø 6 mm
  • 1.9-2.5 N.m Philips No 2
Breaking Capacity
  • 70 kA 690 V
  • 130 kA <= 440 V
Country of Origin Mexico
Weight 0.31 kg
Range Of Product TeSys Ultra
Product Or Component Type limiter disconnector
Range TeSys
Product Compatibility
  • LUB
  • LU2B
Device Short Name LUA
Rohs Exemption Information Yes
Mercury Free Yes
Toxic Heavy Metal Free Yes
Reach Free Of Svhc Yes
Weee The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation X
Eu Rohs Directive Compliant
