LA26300AC – Circuit breaker, LA, I-Line panelboard, 300A, 2 pole, 22kA, 600VAC, 250VDC, AC phase
LA26300AC
Circuit breaker, LA, I-Line panelboard, 300A, 2 pole, 22kA, 600VAC, 250VDC, AC phase

Square D FA/LA Molded Case Circuit Breakers is designed to protect electrical systems from damage caused by overloads. For distribution systems supplied by transformers and distribution systems supplied by engine generator sets.

Brand: Schneider Electric

Add to Quote Catalogue
Specifications
Product Certifications
  • UL Listed
  • CSA
Warranty 18 months
Rohs Exemption Information Yes
Mercury Free Yes
Environmental Disclosure ENVPEP1410004EN
Sustainable Offer Status Green Premium product
Pvc Free Yes
California Proposition 65 WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
China Rohs Regulation Product out of China RoHS scope. Substance declaration for your information.
Circularity Profile N/A
Eu Rohs Directive Compliant with Exemptions
Halogen Content Performance Halogen free plastic parts product
Terminal Identifier AL400LA
Height 11 in
Breaking Capacity Code A
Magnetic Tripping Current 3000-3000 A
Electrical Connection
  • lugs, load
  • I-Line connection, line
Magnetic Hold Current 1500 A
Circuit Breaker Application HACR rated
Mounting Mode I-Line
Poles Description 2P
Line Rated Current 300 A
Width 6 in
Wiring Configuration 2-wire
Depth 5.84 in
Phase Connection AC
Country of Origin Mexico
Width 6 in
Height 11 in
Trip Unit Technology thermal-magnetic
Product Or Component Type circuit breaker
