HMIBX1A0NDA
Essential Edge Controller, Harmony BX1, Ethernet, 2 serial, Linux, 24V DC
Specifications
| Power Consumption In W | 24 W |
|---|---|
| Electrical Connection | screw connector, connector type: pin, 1 way, circuit application: ground - location: bottom |
| Height | 140.76 mm |
| Control Type | resettable |
| [Us] Rated Supply Voltage | 24 V DC power supply |
| Inrush Current | 6 A |
| Number Of Slots | 2 slot(s) for Mini PCIe Connector (USB signal) |
| Cyber Secured Boot | Secure password boot |
| Main Type | Essential |
| Net Weight | 950 g |
| Depth | 48 mm |
| Mounting Location | on DIN rail |
| Memory Description | 4 GB RAM LPDDR4 internal not expandable) |
| Supply Voltage Limits | 9-36 V |
| Free Slots | 1 microSD SD 3.0, max raw transfer rate 104 MBps Supports SD,SDHC,SDXC |
| Number Of Slots Available For Expansion | 2 Mini PCIe Connector (USB signal) |
| Integrated Connection Type |
|
| Display Resolution | 1920 x 1080 pixels at 60 Hz |
| Width | 98.2 mm |
| Type Of Cooling | fanless |
| Data Storage Equipment | 32 GB eMMC (soldered) |
| Ambient Air Temperature For Operation | -10-55 °C |
| Standards |
|
| Product Certifications |
|
| Ambient Air Temperature For Storage | -40-80 °C |
| Quality Labels | CE |
| Relative Humidity | 10-95 % non condensing |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP2405013EN |
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI2405013EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Country of Origin | Taiwan |
| Width | 98.2 mm |
| Height | 140.76 mm |
| Weight | 950 g |
| Range Of Product | Harmony iPC |
| Software Package | EAE V 23.0 default |
| Product Or Component Type | essential edge controller |
| Processor Name | ARM Cortex-A53 quad core 1.6 GHz NXP i.MX8M Plus |
| Device Short Name | essential edge controller |
| Operating System | Linux Debian 11 |
