GJL36030M04
MOTOR CIRCUIT PROTECTOR 600Y/347V 30A
Specifications
| Country of Origin | United States |
|---|---|
| Product Certifications |
|
| Mounting Mode | unit mount |
| Range Of Product | GJL |
| Magnetic Tripping Current | 90-330 A |
| Poles Description | 3P |
| Electrical Connection | lugs |
| Line Rated Current | 30 A |
| Product Or Component Type | Motor Circuit Protector |
| Awg Gauge |
|
| [Ue] Rated Operational Voltage | 600Y/347 V AC |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Pvc Free | Yes |
| Eu Rohs Directive | Compliant with Exemptions |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Halogen Content Performance | Halogen free product |
| Warranty | 18 months |
