EZM3BUSLF
Meter accessory, EZ Meter-Pak, busway transition section, 1200A, 3 phase, left, neutral front
Specifications
| Nema Degree Of Protection | NEMA 1 |
|---|---|
| Warranty | 18 months |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Eu Rohs Directive | Compliant with Exemptions |
| Product Certifications | UL Listed |
| Height | 23.25 in |
| Device Mounting | surface |
| Bus Rated Current | 1200 A |
| Enclosure Material | steel |
| Width | 12.00 in |
| Wiring Configuration | 4-wire |
| Depth | 9.12 in |
| Line Rated Current | 1200-1200 A |
| Country of Origin | United States |
| Width | 12.00 in |
| Height | 23.25 in |
| Range Of Product | Meter-Pak |
| Device Short Name | EZ |
