DF14AM2
Auxiliary contact block, TeSys DF, 2NC, 5A, disconnector, signalling contact, instantaneous
Specifications
| Ambient Air Temperature For Operation | -20-60 °C |
|---|---|
| Ambient Air Temperature For Storage | -40-80 °C |
| Warranty | 18 months |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Toxic Heavy Metal Free | Yes |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
| Eu Rohs Directive | Compliant |
| Minimum Switching Current | 30 mA |
| [Ith] Conventional Free Air Thermal Current | 5 A |
| [Ue] Rated Operational Voltage |
|
| Range Compatibility | TeSys TeSys DF |
| Net Weight | 0.029 kg |
| Minimum Switching Voltage | 10 V |
| [Ui] Rated Insulation Voltage | 250 VAC |
| Country of Origin | France |
| Weight | 0.029 kg |
| Product Or Component Type | auxiliary contact block |
| Connections - Terminals | Faston connector |
| Range | TeSys |
| Pole Contact Composition | 2 NC |
| Auxiliary Contacts Operation | instantaneous |
| Device Short Name | DF14 |
