Relay Type | output relay |
---|---|
Range Of Product | Advantys Telefast ABE7 |
Quantity Per Set | set of 4 |
Product Or Component Type | plug-in solid state relay |
Warranty | 18 months |
Voltage State 1 Guaranteed | 18.6 V DC |
Current State 0 Guaranteed | 0.4 mA DC |
Discrete Input Voltage | 24 V DC |
Response Time |
|
Current State 1 Guaranteed | 6.5 mA DC |
Discrete Output Current | 500 mA |
Product Compatibility |
|
Voltage State 0 Guaranteed | 2.8 V DC |
Net Weight | 0.016 kg |
Width Pitch Dimension | 10 mm |
Discrete Output Voltage | 24...240 V AC |
China Rohs Regulation | X |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP1409004EN |
Sustainable Offer Status | Green Premium product |
Pvc Free | Yes |
Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
