plug-in solid state relay- 12.5 mm - input - 24 V DC type 2
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for Telefast pre-wired system. This plug-in solid state relay is compatible with Modicon ABE7 connection sub-bases. It is a solid state input relay with a discrete input voltage of 24V DC. The response time is ≤0.05ms from state 0 to 1 and ≤0.4ms from state 1 to 0. The width pitch is 12mm. It weighs 0.014kg. It is suitable for all types of industrial applications. This product is suitable for use with Modicon ABE7P16F310, ABE7P16F310E and ABE7P16F312 sub-base. Modicon ABE7 means greater simplicity to rationalise wiring in your automation system equipment. Pre-wired system enabling connection and adaptation of control signals of PLC cards equipped with HE10 connectors.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Relay Type | input relay |
|---|---|
| Range Of Product | Advantys Telefast ABE7 |
| Quantity Per Set | set of 4 |
| Product Or Component Type | plug-in solid state relay |
| Warranty | 18 months |
| Discrete Input Voltage | 24 V DC, type 2 |
| Response Time |
|
| Product Compatibility |
|
| Net Weight | 0.014 kg |
| Width Pitch Dimension | 12 mm |
| Discrete Output Voltage | 5...24 V DC |
| China Rohs Regulation | X |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1409004EN |
| Sustainable Offer Status | Green Premium product |
| Pvc Free | Yes |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
