NEMA Contactor and NEMA Motor Starter, Type S, replacement coil, 110/120VAC 50/60Hz, NEMA size 00 series B
Type S nonreversing magnetic contactors are used to switch heating loads, capacitors, transformers, and electric motors where overload protection is provided separately. Type S non-reversing magnetic NEMA motor starters are for motor control applications. The coil can be easily replaced in a Type S contactor or starter. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor if the coil were to fail. This coil is used in an 8502SA NEMA contactor or 8635SA NEMA motor starter. The coil is rated for 110/120 VAC 50/60 Hz. The inrush power of this coil is 165 VA. It has an average sealed consumption of 30 VA. This coil has a height of 2.15 inches, a width of 3.21 inches and a depth of 2.21 inches. Coil is fully encapsulated to protect it. Coil has screw clamp connections.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Average Consumption | 33 VA |
|---|---|
| Series Name | B |
| [Ue] Rated Operational Voltage |
|
| Height | 54.7 mm |
| Nema Size | 00 |
| Inrush Power In Va | 165 VA |
| Width | 81.5 mm |
| Depth | 56.2 mm |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Eu Rohs Directive | Under investigation |
| Country of Origin | Mexico |
| Width | 81.5 mm |
| Height | 54.7 mm |
| Accessory / Separate Part Destination | class 8536 type S starter |
| Product Or Component Type | coil |
| Warranty | 18 months |
