9080GA6
Terminal block, Linergy, flat terminal connector, natural colored block, 40A, 600V
Square D 2510M and T integral horsepower manual motor starters provide overload protection and On Off control for small AC motors. Starters can be locked in the Off or Stop position to prevent inadvertent operation. Pilot lights and auxiliary contacts are field addable. Each terminal is approved for use with 1 or 2 #12 wires, 1 or 2 #14 wires, 1 or 2 #16 wires, 1 or 2 #18 wires, 1 or 2 #20 wires, or 1 or 2 #22 wires. A variety of enclosures are available. Starters are UL Listed and CSA Certified for global applications.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Number Of Terminal Blocks | 32 per foot |
|---|---|
| Product Certifications |
|
| Ambient Air Temperature For Operation | -40-257 °F |
| Height | 1.48 in |
| Connections - Terminals | screw terminal zinc plated steel 18-20 lbf.in : AWG 22...AWG 12 copper) |
| Mounting Support |
|
| Electrical Connection | ring tongue |
| Line Rated Current |
|
| Awg Gauge | AWG 22...AWG 12 copper |
| Width | 1.8 in |
| Depth | 0.37 in |
| Product Compatibility | GP6B |
| Protection Type | fingersafe DIN 57470 |
| [Ue] Rated Operational Voltage | 600 V AC/DC |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Pvc Free | Yes |
| Toxic Heavy Metal Free | Yes |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
| Eu Rohs Directive | Compliant |
| Country of Origin | Mexico |
| Width | 1.8 in |
| Height | 1.48 in |
| Range Of Product | 9080G |
| Localisation On Device | standard |
| Product Or Component Type | terminal block |
| Color | natural |
| Quantity Per Set | set of 50 |
| Warranty | 18 months |
Documents
- 9080G Terminal Blocks Installation Instructions - 65013-006-40Q (pdf)
- Spec Sheet
- Square D NEMA Type Terminal Blocks Catalog - 9080CT9601+Terminal+Blocks+Catalog (pdf)
- Digest Catalog 24: Terminal Blocks (MAY 2019) - 0100CT1901_SEC-24 (pdf)
- Terminal Blocks: Section 21 - Digest 179 (2024) - Terminal-Blocks-Digest-Catalog-0100CT2401-SEC-21 (pdf)
