9066RB1
Starter external reset mechanism kit, 8538/8539, NEMA Size 0 and 1, NEMA 1/12
External reset mechanism allows the reset of the Type S overload relay without open the enclosure. The grey push button operator is mounted into the cover of the NEMA 1 or 12 enclosure. The push button is marked RESET. This kit is designed to provide external overload relay resetting for 8538 and 8539 combination starters.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
|---|---|
| Eu Rohs Directive | Under investigation |
| Warranty | 18 months |
| Country of Origin | Mexico |
| Product Destination | reset mechanism kit |
| Range Of Product | type S |
| Mounting Support | enclosure door |
Documents
- NEMA and Definite Purpose Contactors and Starters: Section 16 - Digest 179 (2024) - NEMA-Contactors-Digest-Catalog-0100CT2401-SEC-16 (pdf)
- Digest Catalog 16: NEMA and Definite Purpose Contactors and Starters - 0100CT1901_SEC-16 (pdf)
- Spec Sheet
- 30072-100-48 Instruction Sheet for 9066RB1 and RB2 - 30072-100-48++9066RB1-RB2 (pdf)
