9001KP35 - Head for pilot light, Harmony 9001K, metal, without cap, 30mm, 24...28V

9001KP35

This Harmony 9001KP35 is a pilot light 28V. It is part of the range Harmony 9001 K diameter 30mm metal push buttons, switches, pilot lights.

Add to Quote Catalogue

Product Certifications	CSA LR25490 class 3211 03 UL listed file E42259 CCN NKCR CE
Nema Degree Of Protection	NEMA 1/2/3/3R/4/6/12/13
Warranty	18 months
Rohs Exemption Information	Yes
Mercury Free	Yes
California Proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Weee	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation	X
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
[Us] Rated Supply Voltage	24...28 V
Light Source	incandescent bulb
Mounting Diameter	30 mm
Light Block Supply	full voltage
Operating Mode	normal
Cap/Operator Or Lens Colour	without cap
Size	30 mm
Bezel Material	metal
Shape Of Screw Head	round
Bulb Base	BA 9s
Country of Origin	Mexico
Range Of Product	Harmony 9001K
Product Or Component Type	head for pilot light
Device Short Name	K
