Modicon Momentum - high speed counter module base - 6 I / 4 O
This counter module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This high speed counter module base has 2 groups of 3 discrete inputs and 2 groups of 2 discrete outputs with positive discrete input logic. It is a module with discrete input voltage ranges from -3V DC to 30V DC, 24V DC and discrete output voltage of 24V. It is furnished with 2 removable terminal blocks for electrical connection. It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Group Of Channels |
|
|---|---|
| Range Of Product | Modicon Momentum automation platform |
| Product Or Component Type | high speed counter module base |
| Discrete Output Number | 4 |
| Number Of Counter | 2 |
| Discrete Input Number | 6 |
| Warranty | 18 months |
| Electrical Connection | 2 connectors for removable terminal blocks |
| Discrete Output Logic | positive |
| Discrete Input Voltage |
|
| Maximum Voltage Drop | <0.5 V 0.5 A at state on |
| Current Consumption | 280 mA 24 V DC |
| Marking | CE |
| Current State 0 Guaranteed | <= 1.2 mA |
| Surge Current | 5 A 1 ms |
| Response Time |
|
| Discrete Output Current |
|
| Net Weight | 0.21 kg |
| Voltage State 0 Guaranteed | <= 5 V |
| Counter Inputs Resolution | 24 bits + sign |
| Discrete Output Voltage | 24 V |
| Maximum Leakage Current | 1 mA DC 24 V |
| Current State 1 Guaranteed | >= 2.5 mA |
| Counting Input Voltage |
|
| Counting Input Type |
|
| Discrete Input Logic | positive |
| Counter Configuration | via comm adapter |
| Input Overvoltage Protection | 45-45 V 10 s |
| Counting Frequency |
|
| Voltage State 1 Guaranteed | >= 11 V |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1403005EN |
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI1403005EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Product Certifications |
|
| Ambient Air Temperature For Operation | 0-60 °C |
| Resistance To Electromagnetic Fields | 10 V/m 80...1000 MHz IEC 801-3 |
| Ambient Air Temperature For Storage | -40-85 °C |
| Relative Humidity | 95-95 % without condensation |
| Resistance To Electrostatic Discharge |
|
| Protective Treatment | TC |
| Operating Altitude | <= 16404.2 ft (5000 m) |
