discrete output module Modicon Momentum - 16 O solid state
This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base DC module offers 2 groups of 8 outputs, 16 discrete outputs with solid state switch type. It offers discrete output voltage of 24V DC. There is an isolation between channels and bus at 500V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Discrete Output Type | solid state switch |
|---|---|
| Group Of Channels | 2 groups of 8 outputs |
| Range Of Product | Modicon Momentum automation platform |
| Current Per Channel | 0.5 A |
| Product Or Component Type | discrete output base DC |
| Discrete Output Voltage | 24 V DC |
| Discrete Output Number | 16 |
| Short-Circuit Protection | outputs electronically protected |
| Protective Treatment | TC |
| Warranty | 18 months |
| Power Dissipation |
|
| Height | 141.5 mm |
| [Ue] Rated Operational Voltage | 24 V DC |
| Terminals Description Plc N°1 |
|
| Maximum Voltage Drop | <0.5 V 0.5 A at state 1 |
| Response Time |
|
| Current Consumption | 250 mA 24 V DC |
| Surge Current | 5 A 1 ms |
| Marking | CE |
| Discrete Output Current |
|
| Net Weight | 0.21 kg |
| Maximum Leakage Current | 1 mA 24 V DC |
| Local Signalling | for channel status 16 LEDs |
| Output Overload Protection | outputs electronically protected |
| Width | 125 mm |
| Depth | 47.5 mm |
| Isolation Between Channels And Bus | 500 V AC |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1403005EN |
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI1403005EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Product Certifications |
|
| Ambient Air Temperature For Operation | 0-60 °C |
| Resistance To Electromagnetic Fields | 10 V/m 80...1000 MHz IEC 801-3 |
| Ambient Air Temperature For Storage | -40-85 °C |
| Relative Humidity | 95-95 % without condensation |
| Resistance To Electrostatic Discharge |
|
| Operating Altitude | <= 16404.2 ft (5000 m) |
