Multi9 - comb busbar - 1L - 18 mm pitch - 12 modules - 100A
This Multi9 product is a comb busbar 12 modules. It is dedicated to (Line) installations. The distribution type is 1L. It is insulated and uncuttable. It is a set of 1 device. It is suitable for 12 devices (1P). This comb busbar is compatible with Multi9 C60SP devices. The total number of modules of 18mm is 12. The Ue rated operational voltage is 277VAC (phase to neutral) and 480VAC (phase to phase). The Ui rated insulation voltage is 690VAC. Its width is 216mm. The color is light grey (RAL 7035). The pollution degree is 3. The resistance of the plastic to flames and to abnormal heat is 960°C within 30s.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Total Number Of 18 Mm Modules | 12 |
|---|---|
| Accessory / Separate Part Category | connection accessory |
| Product Or Component Type | comb busbar |
| Range | Multi9 |
| Mounting Mode | horizontal |
| Lines Description | 1L |
| Warranty | 18 months |
| Range Compatibility | Multi9 (Multi9 C60SP) |
| Number Of Ways | 12 ways 1 L |
| 9 Mm Pitches | 24 |
| Distance Between Way | 18 mm |
| Marking | L |
| Connector Type | tooth |
| Device Presentation | uncuttable |
| [Ui] Rated Insulation Voltage | 690 V AC |
| [Ie] Rated Operational Current | 100 A 40 °C |
| Insulation | insulated |
| [Ue] Rated Operational Voltage |
|
| Connection Pitch | 18 mm |
| [Uimp] Rated Impulse Withstand Voltage | 12 kV |
| Color | Light gray RAL 7035) |
| Width | 216 mm |
| Mounting Location | top tunnel type terminals |
| Poles Configuration For 1 Way | 1 x 1P |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
| Eu Rohs Directive | Compliant |
| Standards |
|
| Fire Resistance | 960 °C 30 s ) |
