| Range Of Product |
OsiSense XX |
| Sensor Type |
Ultrasonic sensor |
| Series Name |
General purpose |
| Sensor Name |
XX5 |
| Sensor Design |
Cylindrical M12 |
| Detection System |
Diffuse |
| Material |
Plastic |
| Type Of Output Signal |
Discrete |
| [Us] Rated Supply Voltage |
12...24 V DC reverse polarity protection |
| IP Degree Of Protection |
IP67 IEC 60529 |
| Supply Voltage Limits |
10…28 V DC |
| Maximum Switching Current |
100 mA overload and short-circuit protection |
| Voltage Drop |
1 V |
| Delay First Up |
20 ms |
| Marking |
CE |
| Standards |
IEC 60947-5-2 |
| Product Certifications |
UL |
| Ambient Air Temp For Op |
-4…149 °F (-20…65 °C) |
| Ambient Air Temp For Storage |
-40…176 °F (-40…80 °C) |
| Vibration Resistance |
+/-1 mm 10…55 Hz)IEC 60068-2-6 |
| Shock Resistance |
30 gn in all 3 axes 11 ms IEC 60068-2-27 |
| Resist Electrostatic Dischrg |
8 kV level 4 IEC 61000-4-2 |
| Resist To Electromagn Fields |
9.14 V/m (10 V/m) level 3 IEC 61000-4-3 |
| Category |
22490 - SENSORS-ULTRASONIC (XX5,6) |
| Discount Schedule |
DS2 |
| GTIN |
03389119129244 |
| Nbr. Of Units In Pkg. |
1 |
| Country Of Origin |
US |
| EU RoHs Directive |
Not applicable, out of EU RoHS legal scope |
| Warranty |
18 months |
