| Range Of Product |
OsiSense XX |
| Sensor Type |
Ultrasonic sensor |
| Series Name |
General purpose |
| Sensor Name |
XX5 |
| Sensor Design |
Cylindrical M12 |
| Detection System |
Diffuse |
| Sn Nominal Sensing Distance |
0.16 ft (0.05 m) fixed |
| Material |
Plastic |
| Type Of Output Signal |
Discrete |
| Discrete Output Function |
2 NO |
| Wiring Techniquees |
4-wire |
| Discrete Output Type |
PNP and NPN |
| [Us] Rated Supply Voltage |
12...24 V DC reverse polarity protection |
| Electrical Connection |
Cable M8 4 pins, 9.84 ft (3 m) |
| Sd Sensing Range |
0.02…0.17 ft (0.0064…0.051 m) |
| Beam Angle |
11 ° |
| IP Degree Of Protection |
IP67 IEC 60529 |
| Enclosure Material |
ULTEM |
| Front Material |
Epoxy |
| Thread Type |
M12 x 1 |
| Supply Voltage Limits |
10…28 V DC |
| Sa Assured Operating Distance |
0.02…0.17 ft (0.0064…0.051 m) |
| Maximum Differential Travel |
0.03 in (0.7 mm) |
| Blind Zone |
0.00…0.25 in (0…6.4 mm) |
| Transmission Frequency |
500 kHz |
| Repeat Accuracy |
0.7 % |
| Deviation Angle From 90° |
-10…10 ° |
| Min Size Of Detected Object |
Cylinder diameter 2.5 mm
Flat bar 1 mm wide |
| Status Led |
Supply on 1 LED green)
Output state 1 LED yellow) |
| Current Consumption |
25 mA |
| Maximum Switching Current |
100 mA overload and short-circuit protection |
| Voltage Drop |
1 V |
| Switching Frequency |
<= 125 Hz |
| Delay First Up |
20 ms |
| Delay Response |
2 ms |
| Delay Recovery |
2 ms |
| Marking |
CE |
| Threaded Length |
1.50 in (38 mm) |
| Height |
0.47 in (12 mm) |
| Width |
0.47 in (12 mm) |
| Depth |
1.97 in (50 mm) |
| Product Weight |
0.02 lb(US) (0.011 kg) |
| Standards |
IEC 60947-5-2 |
| Product Certifications |
UL |
| Ambient Air Temp For Op |
-4…149 °F (-20…65 °C) |
| Ambient Air Temp For Storage |
-40…176 °F (-40…80 °C) |
| Vibration Resistance |
+/-1 mm 10…55 Hz)IEC 60068-2-6 |
| Shock Resistance |
30 gn in all 3 axes 11 ms IEC 60068-2-27 |
| Resist Electrostatic Dischrg |
8 kV level 4 IEC 61000-4-2 |
| Resist To Electromagn Fields |
9.14 V/m (10 V/m) level 3 IEC 61000-4-3 |
