VZ7
TeSys VARIO – auxiliary contact block – 1 NC early-break+1 NO late-make
VZ7 is an add-on auxiliary contact module for TeSys Vario switch-disconnectors from Schneider Electric. To be used with V02 to V6 switch bodies, mounted on one side of the switch body. It includes 1NO+1NC contacts (late make NO, early break NC) rated for AC operation until 690V and DC operation until 250V. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHs/Reach). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Add to Quote CatalogueSpecifications
| Part Number | VZ7 |
|---|---|
| Country of Origin | CZ |
| UPC | 785901305743 |
| UPC11 | 78590130574 |
| EAN | 3389110551969 |
| Availability | S |
| Lead Time | 3 |
| UNSPSC | 39122233 |
| ECCN | EAR99 |
| HTs Code | 8536509025 |
| RoHS Compliant | Yes |
| Discount Schedule | CP1 |
| Return Indicator | Yes |
| Depth | 1.91 inch |
| Height | 2.56 inch |
| Width | 0.79 inch |
| Weight | 0.11 pound |
Characteristics
| Range | TeSys |
|---|---|
| Device Short Name | VZ |
| Product Or Component Type | Auxiliary contact block |
| Performance Level | High performance |
| Contacts Type And Composition | 1 NO + 1 NC |
| Contact Operation | Late-make 1 NO Early-break 1 NC |
| Product Compatibility | V2 V5 V02 V6 V1 V4 V01 V0 V3 |
| Network Type | AC DC |
| Network Frequency | 50/60 Hz |
| Mounting Location | Right |
| Ue Rated Operational Voltage | 690 V AC 50/60 Hz |
| Uimp Rated Imp Wstd Voltage | 8 kV |
| Ith Cnvtl Free Air Therm Crrt | 12 A |
| Ithe Cnvtl Enclosed Therm Crrt | 10 A |
| Mechanical Durability | 100000 cycles |
| Electrical Durability | 30000 cycles DC-11 100000 cycles AC-15 |
| Connections - Terminals | screw clamp terminals 2 0.00…0.00 in² (0.75…1.5 mm²) flexible - with cable end screw clamp terminals 2 0.00…0.00 in² (1…2.5 mm²) solid |
| Tightening Torque | 6.20 lbf.in (0.7 N.m) screw clamp terminals |
| Height | 2.56 in (65 mm) |
| Width | 0.79 in (20 mm) |
| Depth | 1.91 in (48.5 mm) |
| Product Weight | 0.11 lb(US) (0.05 kg) |
| Standards | IEC 60947-5 |
| Product Certifications | GL CSA UL |
| Protective Treatment | TC |
| IP Degree Of Protection | IP20 IEC 60529 |
| Ambient Air Temp For Op | -4…122 °F (-20…50 °C) |
| Fire Resistance | 1760 °F (960 °C) IEC 60695-2-1 |
| Category | 21730 - V VARIO SWITCH |
| Discount Schedule | CP1 |
| GTIN | 00785901305743 |
| Nbr. Of Units In Pkg. | 1 |
| Country Of Origin | CZ |
| Green Premium Status | Green Premium product |
| REACh Free Of SVHC | Yes |
| EU RoHs Directive | Compliant |
| Toxic Heavy Metal Free | Yes |
| Mercury Free | Yes |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Warranty | 18 months |
