TeSys Mini-VARIO – Switch body for switch-disconnector – 3 poles – 20 A
VN20 is a 3-pole switch body for TeSys Vario switch-disconnector from Schneider Electric for motor applications 5.5kW@400V AC-23. It requires an operating handle and extension shaft to form a complete unit for enclosure mounting. VN20 is a 3-pole switch body for TeSys Vario switch-disconnector from Schneider Electric. Rated 20A 690V, it is used in motor applications 5.5kW@400V AC-23. It requires an operating handle and extension shaft to form a main or emergency stop switch disconnector. Add-on modules (main pole, neutral pole, earthing module, auxiliary contacts) can complete the assembly. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC, Marine) and Green Premium compliant (RoHs/Reach). Vario 3-pole switch body for rotary switch disconnector assemblies. Rated for 690V AC operation, DC operation is permitted until 250V, performance depending on the number of contacts in series. Possible attachment of 2 add-on poles (1 on each side) , main (VZN12), neutral (VZN11), earthing (VZN14), auxiliary (VZN05, VZN06).
Add to Quote CatalogueSpecifications
| Part Number | VN20 |
|---|---|
| Country of Origin | CZ |
| UPC | 785901759843 |
| UPC11 | 78590175984 |
| EAN | 3389110759846 |
| Availability | S |
| Lead Time | 33 |
| UNSPSC | 39122233 |
| ECCN | EAR99 |
| HTs Code | 8536509040 |
| RoHS Compliant | Yes |
| Discount Schedule | CP1 |
| Return Indicator | Yes |
| Depth | 2.44 inch |
| Height | 1.83 inch |
| Width | 2.20 inch |
| Weight | 0.24 pound |
Characteristics
| Range | TeSys |
|---|---|
| Product Name | TeSys Mini-VARIO |
| Product Or Component Type | Switch body |
| Performance Level | Standard |
| Poles Description | 3P |
| Contacts Type And Composition | 3 NO |
| Network Type | AC DC |
| Network Frequency | 50/60 Hz |
| Mounting Support | Symmetrical rail |
| Ue Rated Operational Voltage | 690 V AC 50/60 Hz |
| Uimp Rated Imp Wstd Voltage | 6 kV |
| Ith Cnvtl Free Air Therm Crrt | 20 A |
| Ithe Cnvtl Enclosed Therm Crrt | 16 A |
| Ie Rated Operational Current | 11 A AC-23)400 V |
| Rated Opr Power In W | 11 kW 690 V AC-23A) 3 kW 230...240 V AC-3) 4 kW 400...415 V AC-3) 5.5 kW 500 V AC-3) 5.5 kW 690 V AC-3) 7.5 kW 500 V AC-23A) 4 kW 230...240 V AC-23A) 5.5 kW 400...415 V AC-23A) |
| Intermittent Duty Class | 30 |
| Making Capacity ( I Rms) | 200 A 400 V AC-21A 200 A 400 V AC-22A 200 A 400 V AC-23A |
| Icm Rated Sc Making Cap | 0.5 kA 400 V at Ipeak |
| [Icw] Rated Short-Time Withstand Rms Current | 140 A 400 V 1 s |
| Rtd Cond Short-Cct Current | 6 kA 400 V 20 A aM 6 kA 400 V 20 A gG |
| Breaking Capacity | 200 A 400 V AC-21A) 200 A 400 V AC-22A) 200 A 400 V AC-23A) |
| Mechanical Durability | 50000 cycles |
| Electrical Durability | 30000 cycles DC-1...5 50000 cycles AC-21 |
| Suitability For ISOlation | Yes |
| Connections - Terminals | Power circuit screw clamp terminals 0.01 in² (4 mm²) solid Power circuit screw clamp terminals 0.01 in² (4 mm²) flexible - with cable end |
| Tightening Torque | Power circuit 6.20 lbf.in (0.7 N.m) screw clamp terminals |
| Height | 1.83 in (46.5 mm) |
| Width | 2.20 in (56 mm) |
| Depth | 2.44 in (62 mm) |
| Product Weight | 0.24 lb(US) (0.11 kg) |
| Standards | IEC 60947-3 |
| Product Certifications | GL UL CSA |
| Protective Treatment | TC |
| IP Degree Of Protection | IP20 IEC 60529 |
| Mechanical Robustness | Shocks 11 ms 15 gn) IEC 60068-2-27 Vibrations 10...150 Hz 1 gn) IEC 60068-2-6 |
| Ambient Air Temp For Op | -4…122 °F (-20…50 °C) |
| Fire Resistance | 1760 °F (960 °C) IEC 60695-2-1 |
| Category | 21730 - V VARIO SWITCH |
| Discount Schedule | CP1 |
| GTIN | 00785901759843 |
| Nbr. Of Units In Pkg. | 1 |
| Country Of Origin | CZ |
| Green Premium Status | Green Premium product |
| EU RoHs Directive | Compliant |
| Mercury Free | Yes |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Pvc Free | Yes |
| Halogen Content Performance | Halogen free product |
| Warranty | 18 months |
