TeSys Mini-VARIO – auxiliary contact block – 1 NC
VZN06 is an add-on auxiliary contact module for TeSys Vario switch-disconnectors from Schneider Electric. For use with Vario switch types VN12 and VN20, it includes 1NC contact rated for AC and DC operation. VZN06 is an add-on auxiliary contact module for TeSys Vario switch-disconnectors from Schneider Electric. For use with Vario switch types VN12 and VN20, it is mounted on one side of the switch body. It includes 1NC contact rated for AC operation until 690V and DC operation until 250V. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC) and Green Premium compliant (RoHs/Reach). Auxiliary contacts module, including 1NC “early break” contact, for Vario switch types VN12 and VN20. Rated for operation in AC-15 operation until 690V and DC-01 operation until 250V. To be installed on one side of a switch body.
Add to Quote CatalogueSpecifications
| Part Number | VZN06 |
|---|---|
| Country of Origin | CZ |
| UPC | 785901760061 |
| UPC11 | 78590176006 |
| EAN | 3389110760064 |
| Availability | N |
| Lead Time | 21 |
| UNSPSC | 39122233 |
| ECCN | EAR99 |
| HTs Code | 8538908140 |
| RoHS Compliant | Yes |
| Discount Schedule | CP1 |
| Return Indicator | No |
| Depth | 1.54 inch |
| Height | 1.79 inch |
| Width | 0.47 inch |
| Weight | 0.04 pound |
Characteristics
| Range | TeSys |
|---|---|
| Device Short Name | VZN |
| Product Or Component Type | Auxiliary contact block |
| Performance Level | Standard |
| Contacts Type And Composition | 1 NC |
| Contact Operation | Early-break |
| Product Compatibility | VN12 VN20 |
| Mounting Location | Left Right |
| Range Compatibility | TeSys VARIO VCFN switch disconnector |
| Ue Rated Operational Voltage | 690 V AC 50/60 Hz |
| Uimp Rated Imp Wstd Voltage | 6 kV |
| Ith Cnvtl Free Air Therm Crrt | 6 A |
| Ithe Cnvtl Enclosed Therm Crrt | 4 A |
| Mechanical Durability | 50000 cycles |
| Electrical Durability | 30000 cycles DC-11 50000 cycles AC-21 |
| Connections - Terminals | screw clamp terminals 2 0.00…0.00 in² (0.75…1.5 mm²) flexible - with cable end screw clamp terminals 2 0.00…0.00 in² (1…2.5 mm²) solid |
| Tightening Torque | 6.20 lbf.in (0.7 N.m) screw clamp terminals |
| Height | 1.79 in (45.5 mm) |
| Width | 0.47 in (12 mm) |
| Depth | 1.54 in (39 mm) |
| Product Weight | 0.04 lb(US) (0.02 kg) |
| Standards | IEC 60947-5 |
| Product Certifications | CSA GL UL |
| Protective Treatment | TC |
| IP Degree Of Protection | IP20 IEC 60529 |
| Ambient Air Temp For Op | -4…122 °F (-20…50 °C) |
| Fire Resistance | 1760 °F (960 °C) IEC 60695-2-1 |
| Category | 21730 - V VARIO SWITCH |
| Discount Schedule | CP1 |
| GTIN | 00785901760061 |
| Nbr. Of Units In Pkg. | 1 |
| Country Of Origin | CZ |
| Green Premium Status | Green Premium product |
| REACh Free Of SVHC | Yes |
| EU RoHs Directive | Compliant |
| Toxic Heavy Metal Free | Yes |
| Mercury Free | Yes |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Warranty | 18 months |
