| Lead Time |
Special Order - Call for Quoted Lead Times |
| Provided Equipment |
Assembly service
Start-Up Service
User Manual
Installation guide |
| Number Of Rack Unit |
0U |
| Colour |
Light gray NCS 2703-G84Y) |
| Depth |
42.01 in (106.7 cm) |
| Height |
80.00 in (203.2 cm) |
| Product Weight |
12004.18 lb(US) (5445 kg) |
| Width |
155.87 in (395.9 cm) |
| Network Frequency |
60 Hz programmable +/- 0.5 / 1 / 2 / 4 / 6 / 8% |
| Number Of Input Connectors |
1 Hard Wire 4-wire (3PH + G) |
| Input Voltage Limits |
408...552 V adjustable 480 V
408...552 V 480 V |
| Maximum Input Current |
1364 A |
| Max Short Time Withstd Current |
200 kA |
| Input Protection Type |
3-pole breaker |
| Input Voltage |
3 phase |
| Rated Power In W |
1000000 W |
| Max Configurable Power In W |
1000000 W |
| Harmonic Distortion |
Less than 5 % at full load |
| Output Frequency |
60 Hz programmable +/- 0.5 / 1 / 2 / 4 / 6 / 8% sync to mains
60 Hz +/- 0.1 % for 60 Hz nominal not synced |
| Crest Factor |
Unlimited |
| Ups Type |
Delta Conversion On-Line |
| Wave Type |
Sine wave |
| Output Connector Type |
Hard Wire 4-wire (3PH + G) 1 |
| Output Voltage |
480 V 3 phase |
| Product Certifications |
CUL Listed
UL Listed |
| Standards |
EN 50091-1
FCC Part 15 class A
ISO 14001
ISO 9001
UL 1778 |
| Ambient Air Temp For Op |
32…104 °F (0…40 °C) |
| Relative Humidity |
0…95 % |
| Operating Altitude |
0...3333 ft |
| Ambient Air Temp For Storage |
-58…104 °F (-50…40 °C) |
| Storage Altitude |
0…50000 ft (0.00…15240.00 m) |
| Acoustic Level |
74 dBA |
| Heat Dissipation |
105600 Btu/h |
| Nema Degree Of Protection |
NEMA 1
NEMA 12 optional) |
| Battery Type |
External battery system |
| Control Panel |
Touch Screen LCD User Interface |
| Alarm |
Audible and visible alarms prioritized by severity |
| Emergency Power Off |
Yes |
| EU RoHs Directive |
Under investigation |
| Optimized Energy Efficiency |
Energy efficient product |
| Warranty |
1 year repair or replace |
