Switch, reversing drum, 5 HP at 575 VAC single phase, 7.5 HP at 575 VAC polyphase, handle operated, NEMA 4 enclosure
2601BW1
Switch, reversing drum, 5 HP at 575 VAC single phase, 7.5 HP at 575 VAC polyphase, handle operated, NEMA 4 enclosure
Specifications
Part Number 2601BW1
Country of Origin MX
UPC 785901784449
UPC11 78590178444
EAN 0785901784449
Availability S
Lead Time 5
Retail Flag true
UNSPSC 39122207
HTs Code 8504330040
Prop 65 This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen & Reproductive harm. For more information go to www.p65warnings.ca.gov
Discount Schedule CP1
Return Indicator No
Characteristics
Product Reversing Drum Switch
Enclosure Rating NEMA 4
Horsepower 1.5 hp 115 V AC, 1 phase 3 hp 230 V AC, 1 phase 5 hp 460 V AC, 1 phase 5 hp 575 V AC, 1 phase 5 hp 200 V AC, 3 phase 5 hp 230 V AC, 3 phase 7.5 hp 460 V AC, 3 phase 7.5 hp 575 V AC, 3 phase 2 hp 115 V DC 2 hp 230 V DC
Maximum Rated Voltage 600 V AC 250 V DC
Number Of Poles 3P
Certifications CSA UL Listed
Electrical Connection Screw-clamp terminals
Type B
Category 21116 - 2601
Discount Schedule CP1
GTIN 00785901784449
Nbr. Of Units In Pkg. 1
Country Of Origin MX
EU RoHs Directive Not compliant
Warranty 18 months
