| Bezel Material |
Black plastic |
| Device Short Name |
K |
| Enclosure Type |
Dust and oil resistant weatherproof enclosure indoor/outdoor |
| Mounting Diameter |
1.18 in (30 mm) |
| Contacts Type And Composition |
Without contact block |
| Light Block Supply |
Via transformer 120 V AC 50/60 Hz
Via transformer 110 V AC 50/60 Hz |
| Operator Pos Information |
2 positions |
| Operator Profile |
Standard knob |
| Operator Profile |
1 projecting push-button |
| Type Of Operator |
Maintained |
| Nema Degree Of Protection |
NEMA 1/2/3/3R/4/4X/6/12/13 |
| Product Certifications |
CSA LR24590 class 3211 03
CE
UL listed file E42259 CCN NKCR |
| Category |
21429 - 9001 SK,SKY |
| Discount Schedule |
CS1 |
| GTIN |
00785901849865 |
| Nbr. Of Units In Pkg. |
1 |
| Country Of Origin |
MX |
| Green Premium Status |
Green Premium product |
| REACh Free Of SVHC |
Yes |
| EU RoHs Directive |
Pro-active compliance (Product out of EU RoHS legal scope) |
| Toxic Heavy Metal Free |
Yes |
| Mercury Free |
Yes |
| WEEE |
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Warranty |
18 months |
