| Range Of Product |
Harmony 9001K |
| Product Or Component Type |
Selector switch |
| Device Short Name |
K |
| Type Of Operator |
maintained |
| Operator Profile |
Black standard knob |
| Bezel Material |
Chromium plated metal |
| Mounting Diameter |
1.18 in (30 mm) |
| Shape Of Signaling Unit Head |
Round |
| Operator Pos Information |
2 positions |
| Contacts Type And Composition |
3 NC |
| Connections - Terminals |
Screw-clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1 |
| Contact Operation |
Standard |
| Device Presentation |
Complete product |
| Nema Degree Of Protection |
NEMA 1/2/3/3R/4/6/12/13 |
| Product Certifications |
UL listed file E42259 CCN NKCR
CSA LR24590 class 3211 03
CE |
| Category |
21426 - 9001 K (NOT KA,KM,KX) |
| Discount Schedule |
CS1 |
| GTIN |
00785901561514 |
| Nbr. Of Units In Pkg. |
1 |
| Country Of Origin |
MX |
| Green Premium Status |
Green Premium product |
| EU RoHs Directive |
Pro-active compliance (Product out of EU RoHS legal scope) |
| Mercury Free |
Yes |
| WEEE |
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Warranty |
18 months |
