This red beacon is part of the range of rotating beacons Harmony XVR diameter 130mm. It is supplied complete and pre-cabled. Supply voltage is 230V AC and degree of protection is IP 66 and IP 67. It is designed for long distance signaling applications, thanks to the use of “super-bright” LED which provides good illuminating power, a long service life and reduced time for maintenance and also energy saving. It is used mainly in the iron and steel industry, on industrial handling vehicles or for safety applications.
Add to Quote CataloguePart Number | XVR13M04L |
---|---|
Country of Origin | ID |
UPC | 785901944843 |
UPC11 | 78590194484 |
EAN | 3389119045322 |
Availability | N |
Lead Time | 50 |
UNSPSC | 32151503 |
ECCN | EAR99 |
HTs Code | 8531809026 |
Prop 65 | This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen & Reproductive harm. For more information go to www.p65warnings.ca.gov |
RoHS Compliant | Yes |
Discount Schedule | XV |
Return Indicator | No |
Weight | 2.18 pound |
Range Of Product | Harmony XVR |
---|---|
Product Or Component Type | Prewired rotating mirror beacon |
Sound Signalling | Without |
Device Short Name | XVR |
Mounting Diameter | 5.12 in (130 mm) |
IP Degree Of Protection | IP66 IEC 60529 IP67 IEC 60529 |
Us Rated Supply Voltage | 230 V AC |
Light Source | High luminosity LED, red |
Material | ABS (acrylonitrile butadiene-styrene) body part PC globe |
Cad Overall Width | 5.12 in (130 mm) |
Cad Overall Depth | 5.12 in (130 mm) |
Product Weight | 2.18 lb(US) (0.99 kg) |
Marking | CE |
Product Mounting | By 3 M6 screws |
Uimp Rated Imp Wstd Voltage | 4 kV |
Current Consumption | 22 mA |
Flashing Frequency | 2.7 Hz |
Clamping Connection Capacity | 1.25 mm² |
Awg Gauge | AWG 18 |
Cable Length | 15.75 in (400 mm) |
Standards | EN/IEC 60947-5-1 EN/IEC 60947-1 |
Protective Treatment | TC |
Ambient Air Temp For Storage | -31…158 °F (-35…70 °C) |
Ambient Air Temp For Op | -22…122 °F (-30…50 °C) |
Electrical Shock Protect Class | Class II IEC 61140 |
Category | 22617 - XVC TOWER LIGHTS |
Discount Schedule | XV |
GTIN | 00785901944843 |
Nbr. Of Units In Pkg. | 1 |
Country Of Origin | ID |
EU RoHs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Mercury Free | Yes |
Warranty | 18 months |
