| Product Or Component Type |
Controllers separate parts |
| Accessory / Separate Part Cate |
Control accessories |
| Product Specific Application |
Light hoisting applications |
| Product Compatibility |
XKB |
| Accessory / Separate Part Type |
Potentiometer |
| Condition Of Use |
For applications requiring an extended neutral zone |
| Ohmic Value |
4700 Ohm |
| Size |
15 mm |
| Standards |
UTE 93-265 |
| Potentiometer Characteristic |
Linear function
Continuous rotational operation |
| Operating Angle |
360 ° |
| Mechanical Durability |
3000000 cycles |
| Centre Tap |
Wired out to terminal |
| Centre Tap Dead Zone |
40 ° |
| Power Dissipation In W |
3 W 185 °F (85 °C) |
| Connections - Terminals |
Flying leads from soldered standard tags |
| Product Weight |
0.12 lb(US) (0.055 kg) |
| Mounting Mode |
By the body |
| Category |
22474 - PUSHBUTTON,CRANE JOYSTICKS |
| Discount Schedule |
I |
| GTIN |
03389110147148 |
| Nbr. Of Units In Pkg. |
1 |
| Country Of Origin |
FR |
| EU RoHs Directive |
Pro-active compliance (Product out of EU RoHS legal scope) |
| Mercury Free |
Yes |
| WEEE |
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Warranty |
18 months |
