This Harmony XB5, illuminated orange selector switch head for integral LED with standard handle has 3 positions, operates with spring return to center mechanism. This illuminated switch head for integral LED provides an ergonomic interface for controlling your machines. It is supplied with standard handle and can easily be installed on compatible selector switch units. It provides a clear help in setting your machines in various operating modes, even in darker control rooms, and with a clear visual feedback. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP69K. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product. It provides high brightness for easy identification of function and operation mode, even in brightly lit environments.
Add to Quote CataloguePart Number | ZB5AK1553 |
---|---|
Country of Origin | FR |
UPC | 785901387145 |
UPC11 | 78590138714 |
EAN | 3389110906233 |
Availability | N |
Lead Time | 23 |
UNSPSC | 39122216 |
ECCN | EAR99 |
HTs Code | 8538908180 |
Prop 65 | This product can expose you to chemicals including: Nickel compounds and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov |
RoHS Compliant | Yes |
Discount Schedule | CS2 |
Return Indicator | No |
Weight | 0.04 pound |
Range Of Product | Harmony XB5 |
---|---|
Product Or Component Type | Head for illuminated selector switch |
Product Compatibility | Integral LED |
Device Short Name | ZB5 |
Bezel Material | Dark grey plastic |
Mounting Diameter | 0.87 in (22 mm) |
Head Type | Standard |
Sale Per Indivisible Qty | 1 |
Shape Of Signaling Unit Head | Round |
Type Of Operator | To centre spring return |
Operator Profile | Orange standard handle |
Operator Pos Information | 3 positions +/- 45° |
Cad Overall Width | 1.14 in (29 mm) |
Cad Overall Height | 1.14 in (29 mm) |
Cad Overall Depth | 1.69 in (43 mm) |
Product Weight | 0.04 lb(US) (0.016 kg) |
Mechanical Durability | 1000000 cycles |
Station Name | XALD 1...5 cut-outs XALK 2...5 cut-outs |
Electrical Composition Code | M3 4 single front mounting integral LED M6 2 single front mounting integral LED and transformer M10 2 single front mounting integral LED MF1 2 single front mounting integral LED MR1 2 single rear mounting integral LED M4 4 single and double front mounting integral LED |
Device Presentation | Basic element |
Protective Treatment | TH |
Ambient Air Temp For Storage | -40…158 °F (-40…70 °C) |
Ambient Air Temp For Op | -40…158 °F (-40…70 °C) |
Overvoltage Category | Class II IEC 60536 |
IP Degree Of Protection | IP66 IEC 60529 IP67 IP69 IP69K |
Nema Degree Of Protection | NEMA 13 NEMA 4X |
Resistance High Press Washer | 1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m |
IK Degree Of Protection | IK06 IEC 50102 |
Standards | EN/IEC 60947-5-5 UL 508 EN/IEC 60947-5-1 EN/IEC 60947-1 JIS C8201-5-1 EN/IEC 60947-5-4 CSA C22.2 No 14 JIS C8201-1 |
Product Certifications | GL CSA LROS (Lloyds register of shipping) RINA BV DNV UL Listed |
Vibration Resistance | 5 gn 2…500 Hz)IEC 60068-2-6 |
Shock Resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
Category | 22467 - PUSHBUTTONS,22MM(PLASTIC) NEW |
Discount Schedule | CS2 |
GTIN | 00785901387145 |
Nbr. Of Units In Pkg. | 1 |
Country Of Origin | FR |
REACh Free Of SVHC | Yes |
EU RoHs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Toxic Heavy Metal Free | Yes |
Mercury Free | Yes |
Warranty | 18 months |
