LSS283427
EcoStruxure Building Expert-Enocean valve drive for bus or RF
Specifications
| Part Number | LSS283427 |
|---|---|
| UPC | 332552010668 |
| UPC11 | 33255201066 |
| EAN | 3606480687914 |
| UNSPSC | 39131702 |
| Depth | 1.38 inch |
| Height | 1.89 inch |
| Width | 2.76 inch |
| Weight | 0.12 pound |
Characteristics
| Range | EcoStruxure Building Expert |
|---|---|
| Product Name | Enocean |
| Product Or Component Type | Room temperature controller |
| Device Application | Temperature control |
| Antenna Type | Integrated |
| Connections - Terminals | Screw terminal, 1.5 mm² |
| Device Mounting | Flush |
| Power Consumption In Va | 9.8 VA |
| Nominal Output Power | 2500 W |
| [Us] Rated Supply Voltage | 100...240 V AC 50 Hz +/- 10 % |
| Number Of Inputs | 10 sensor |
| Product Weight | 0.12 lb(US) (0.055 kg) |
| IP Degree Of Protection | IP20 EN 60529 |
| Market Segment | Small buildings |
| Enclosure Material | ABS Red |
| Height | 1.89 in (48 mm) |
| Width | 2.76 in (70 mm) |
| Depth | 1.38 in (35 mm) |
| Ambient Air Temp For Op | -4…140 °F (-20…60 °C) |
| Standards | EN 61000-6-2:2005 EN 61000-6-3:2007 EN 61000-3-2:2006 EN 61000-3-3:1995 EN 61000-3-3:2001/A1 EN 61000-3-3:2005/A2 EN 60730-1:2002 ETSI EN 301 489-3:2001 |
| Directives | 1999/5/EC - R&TTE directive 2004/108/EC - electromagnetic compatibility |
| GTIN | 07332552010668 |
| EU RoHs Directive | Compliant |
