| Range |
EcoStruxure Building Expert |
| Product Or Component Type |
Gateway |
| Device Short Name |
MPM-GW |
| Device Application |
Metering
HVAC
Lighting |
| Supply |
External supply CSA |
| Processor Name |
ARM9 32-bit 400 MHz |
| Battery Type |
Lithium 3 V |
| Range Compatibility |
zone controller |
| Communication Port Protocol |
BACnet
Ethernet RJ45 10/100 Mbit/s
CANbus 125...500 kbit/s
EnOcean 868 MHz
Zigbee Pro 250 kbps 2400…2483.5 MHz |
| Number Of Devices |
16 ZigBee |
| Antenna Gain |
2.5 dBi 2400…2483.5 MHz
0 dBi 0…868 MHz |
| Antenna Connector Type |
RP-SMA |
| Radio Power |
8 dBm - 101 dBm - Zigbee
18 dBm - 105 dBm - Zigbee
5 dBm - 95 dBm - EnOcean |
| Operating Distance |
<= 100 ft open environment
<= 300 ft open environment |
| [Us] Rated Supply Voltage |
24 V AC 50/60 Hz +/- 15 %
24 V DC +/- 10 % |
| Electrical Insulation Class |
Class II |
| System Requirements |
Firefox
Google Chrome
Internet browser |
| Power Consumption In W |
1.6 W |
| Power Consumption In Va |
5 VA |
| Communication Gateway |
Ethernet/ZigBee |
| Memory Capacity |
64 MB flash
4 GB internal |
| Realtime Clock |
With battery 10000 h) |
| Mounting Mode |
Clip-on |
| Mounting Support |
DIN rail
Wall
Ceiling |
| Height |
7.52 in (191.01 mm) |
| Width |
4.57 in (116.08 mm) |
| Depth |
1.77 in (44.96 mm) |
| Enclosure Material |
ABS |
| Web Server |
Embedded web page |
| Ambient Air Temp For Op |
32…140 °F (-0…60 °C) |
| Ambient Air Temp For Storage |
-4…140 °F (-20…60 °C) |
| Relative Humidity |
0…90 % non-condensing |
| Standards |
UL 916
ICES-003
CSA C22.2 |
| Flame Retardance |
UL94V0-5VB |
| GTIN |
00711426074482 |
| Nbr. Of Units In Pkg. |
1 |
| EU RoHs Directive |
Compliant |
