| Range Of Product |
OsiSense XT |
| Sensor Type |
Capacitive proximity sensor |
| Product Specific Application |
Detection of insulated materials |
| Sensor Name |
XT7 |
| Sensor Design |
Form 40 x 40 x 117 |
| Size |
117 mm |
| Body Type |
Plug-in body |
| Flush Mountability |
Flush mountable |
| Material |
Plastic |
| Enclosure Material |
Plastic |
| Type Of Output Signal |
Discrete |
| Wiring Techniquees |
2-wire |
| Sn Nominal Sensing Distance |
0.59 in (15 mm) |
| Discrete Output Function |
1 NO or 1 NC programmable |
| Output Circuit Type |
AC |
| Electrical Connection |
Screw clamp terminal, 3 x 1.5 mm² |
| Us Rated Supply Voltage |
24...240 V AC 50...60 Hz |
| Delay Response |
20 ms |
| IP Degree Of Protection |
IP67 IEC 60529 |
| Detection Face |
5 positions turret head |
| Differential Travel |
< 0.2 x Sr |
| Repeat Accuracy |
< 0.1 x Sr |
| Cable Entry |
1 entry tapped for Pg 13.5 cable gland |
| Status Led |
Supply state indication 1 LED green)
Output state indication 1 LED yellow) |
| Supply Voltage Limits |
20…264 V AC |
| Residual Current |
1.5 mA open state |
| Switching Frequency |
<= 25 Hz |
| Voltage Drop |
<5.5 V closed) |
| Delay First Up |
150 ms |
| Delay Recovery |
30 ms |
| Maximum Switching Current |
350 mA |
| Marking |
CE |
| Setting-Up |
Sensitivity by potentiometer |
| Depth |
1.57 in (40 mm) |
| Height |
4.61 in (117 mm) |
| Width |
1.57 in (40 mm) |
| Product Weight |
0.49 lb(US) (0.22 kg) |
| Product Certifications |
UL
CSA |
| Ambient Air Temp For Op |
-13…158 °F (-25…70 °C) |
| Category |
22486 - SENSORS, PROXIMITY |
| Discount Schedule |
DS2 |
| GTIN |
00785901741800 |
| Nbr. Of Units In Pkg. |
1 |
| Country Of Origin |
FR |
| EU RoHs Directive |
Pro-active compliance (Product out of EU RoHS legal scope) |
| Mercury Free |
Yes |
| Warranty |
18 months |
