CT-980
Uni-Die™ CT-980 Manual Crimp Tool, 4-750, PK1
The CT-980 Uni-Die™ Dieless Crimping Tool provides a cushioned grip to help prevent hands from slipping on the tool and reduce fatigue. UL Listed and CSA Certified wire range-taking capability on Panduit® Pan-Lug™ Copper Lugs and splices for #4 AWG – 750 kcmil copper code conductor.
Brand: Panduit
Add to Quote Download Spec Sheet PDFFeatures
- Quad-point indent crimping feature with patented centering system, no dies required
- Cushioned grips prevent hands from slipping on tool, reduces fatigue
- Provides UL Listed and CSA Certified wire range-taking capability on Panduit® Pan-Lug™ Copper Lugs and Splices, minimizes connector inventory and saves cost
- Audible “pop-off” valve indicates crimp completion
- Closed head with bolt interlock, flip top style, rotatable 360 degrees
- Light weight due to high quality aluminum housing and crimp head, results in lightweight tool and ease of operation
- 2-stage hydraulic system with rapid advance double action handle and power stroke
- Automatic retraction when operation is complete
- Manual retraction if needed.
- Environmentally-friendly hydraulic oil, biodegradable
Specifications
| Application | Crimps Panduit Copper and Aluminum compression connectors. |
|---|---|
| Crimp Profile | Indenter |
| Tool Type | Dieless |
| Base Material | Steel |
| Compatible Connector | 4 AWG – 750 kcmil Compression Connectors |
| Insulated Tool Head | No |
| Jaw Opening Width (In.) | 1.46 |
| Jaw Opening Width (mm) | 37 |
| Crimp Force (ton) | 6.2 |
| Sub Brand | Uni-Die™ |
| Wire Size | 4 AWG-750 kcmil |
| Crimp Head Rotation (°) | 360 |
| Overall Length (In.) | 20.7 |
| Overall Length (mm) | 525 |
| Overall Width (In.) | 2.9 |
| Overall Width (mm) | 74 |
| Overall Height (In.) | 7.9 |
| Overall Height (mm) | 200 |
| Weight (Kg) | 4.1 |
| Weight (lb) | 9 |
| For Use With | 4 AWG – 750 kcmil Compression Connectors |
| Includes | (1) Steel Tool Case, (1) Cylinder Block and Gage Package |
| Product Type | Hand Crimp Tool |
