KC22-600B
Pan-Lug™ KC22-600B Copper Code Hex Die, Black Oxide, Steel, PK1
The KC22-600B Hex style crimp die is for use with 600 kcmil copper code conductor in Panduit tools: CT-3001/ST, CT-3001/STINT, CT-3001/STUK, CT-3001/STAUS, CT-3001/TO, CT-3001/CCP, CT-3001/CCPINT, CT-3001/CCPUK, CT-3001/CCPAUS, CT-3001/CCPTO.
Brand: Panduit
Add to Quote Download Spec Sheet PDFFeatures
- Color-coded to provide easy matching to color-coding marked on connectors
- Embosses die index number on connector barrels to provide post crimp inspection
- Part number permanently marked on crimping die for easy identification
- Provide hex style crimp results in terminations with premium electrical and mechanical performance
Specifications
| Product Type | Copper Code Hex Die |
|---|---|
| Sub Brand | Pan-Lug™ |
| Application | Crimp dies for Copper Panduit Power Connectors and Splices. |
| Color Code | Green |
| Copper Conductor Size | 600 kcmil |
| Panduit Die Index Number | 600 |
| For Use With | CT-3001/ST and CT-3001/CCP Crimping Tool to Crimp 600 kcmil Copper Code Conductor |
| Connection Type | Crimp |
| Crimp Profile | Hex |
| Base Material | Steel |
| Finish/Coating | Black Oxide |
