CT-920/CV
Pan-Lug™ CT-920/CV Hand Crimping Tool
Features
- High quality, durable tool construction provides long-term dependability
- Cushioned grip prevents hands from slipping on tool, reduces fatigue
- Uses Panduit CD-920 and CD-930 color-coded crimping dies to provide easy matching of crimping die to connector
- Audible “pop-off” valve indicates crimp completion
- Open "C" head, rotatable 350 degrees
- 2-stage hydraulic system: rapid advance double action handle and power stroke
- Automatic retraction when operation is complete
- Manual retraction operation if needed
- Environmentally-friendly hydraulic oil, biodegradable
- 2-layer PVC covered crimp head
Specifications
| Application | Crimps Panduit Copper and Aluminum compression connectors using Panduit Crimping Dies. |
|---|---|
| Tool Type | Die Type |
| Base Material | Steel |
| Insulated Tool Head | Yes |
| Sub Brand | Pan-Lug™ |
| Overall Length (In.) | 22.1 |
| Overall Length (mm) | 560 |
| Overall Width (In.) | 2.9 |
| Overall Width (mm) | 74 |
| Overall Height (In.) | 8.5 |
| Overall Height (mm) | 217 |
| For Use With | Panduit Crimp Dies |
| Includes | (1) Steel Tool Case with Die Storage |
| Product Type | Hand Crimp Tool |
