CD22-3/0
Pan-Lug™ CD22-3/0 Crimp Dies, 3/0, Black Oxide, Steel, PK1
The CD22-3/0 Crimp Die provides circumferential crimp results in terminations with our 3/0 size Battery Cable Lugs. Color-coded and embossed die index number on the connector barrel providing post crimp inspection. Die is used with approved Battery Cable Lug tooling.
Brand: Panduit
Add to Quote Download Spec Sheet PDFSpecifications
| Compatible Connector | A-Series Battery Cable Copper Compression Lugs |
|---|---|
| Product Type | Crimp Die |
| Sub Brand | Pan-Lug™ |
| Color Code | Orange |
| Copper Conductor Size | 3/0 AWG |
| Flex Conductor Size | 3/0 AWG |
| Panduit Die Index Number | 3/0 |
| For Use With | Battery Cable Lugs |
| Crimp Profile | Circumferential |
| Base Material | Steel |
| Finish/Coating | Black Oxide |
| Part Features | Color coded to connector,premium crimp,embosses die number |
