CD-920H-6
Pan-Lug™ CD-920H-6 Crimp Dies
Specifications
| Product Type | Crimp Die |
|---|---|
| Sub Brand | Pan-Lug™ |
| Color Code | Orange |
| Copper Conductor Size | 1/0 AWG |
| Panduit Die Index Number | PH6 |
| For Use With | Crimp die for use with Panduit CT-920, CT-2920, CT-930, CT-2930/L, CT-2930/LE, CT-2931 and CT-2931/E crimp tools and CT-930/CH crimp head, can also be used with Panduit CT-2940/L and CT-2940/LE crimp tools and CT-940CH crimp head with CD-940-DA die adapter sold separately. |
| Crimp Profile | Circumferential |
| Base Material | Steel |
| Maximum Wire Size (mm²) | 2.5 |
| Minimum Wire Size (mm²) | 16 |
| Part Features | Color coded to connector,premium crimp,embosses die number |
