CD-920-4/0
Pan-Lug™ CD-920-4/0 CD-920 Crimp Dies, 4/0, Black Oxide, Steel, PK1
The CD-920-4/0 Crimp Die provides circumferential crimp results in terminations with premium electrical and mechanical performance with Panduit copper compression lugs and splices. Crimping dies and connectors are color-coded for easy matching while the part number is permanently marked on the crimping die for easy identification. Crimp die designed for use with Panduit CT-920, CT-920CH, CT-930, CT-930CH, and CT-2920 tools.
Brand: Panduit
Add to Quote Download Spec Sheet PDFSpecifications
| Product Type | Crimp Die |
|---|---|
| Sub Brand | Pan-Lug™ |
| Application | Crimp dies for Panduit Power Connectors and Splices. |
| Color Code | Purple/Olive |
| Aluminum Conductor Size | 2/0 AWG |
| Copper Conductor Size | 4/0 AWG |
| Metric Class 2r Copper Conductor Size (mm²) | 95 |
| Flex Conductor Size | 3/0 AWG |
| Panduit Die Index Number | P54 |
| For Use With | Crimp die for use with Panduit CT-920, CT-2920, CT-930, CT-2930/L, CT-2930/LE, CT-2931 and CT-2931/E crimp tools and CT-930/CH and CT-930LPCH crimp heads, can also be used with Panduit CT-2940/L and CT-2940/LE crimp tools and CT-940CH crimp head with CD-940-DA die adapter sold separately. |
| Connection Type | Crimp |
| Crimp Profile | Circumferential |
| Base Material | Steel |
| Finish/Coating | Black Oxide |
| Part Features | Color coded to connector,premium crimp,embosses die number |
