CT-920
CT-920 Die Type Crimping Tool, PK1
The CT-920 Manual Hydraulic Crimp Tool is a hand-operated and light weight hydraulic crimping tool that is made of high quality aluminum that provides long-term dependability. The cushion grip prevents hands from slipping and reduces worker fatigue. This tool crimps most Pan-Term® terminals, splices, disconnects, ferrules, and some copper lugs.
Brand: Panduit
Add to Quote Download Spec Sheet PDFFeatures
- High quality, durable tool construction provides long-term dependability
- Cushioned grip prevents hands from slipping on tool, reduces fatigue
- Uses Panduit CD-920 and CD-930 color-coded crimping dies to provide easy matching of crimping die to connector
- Audible “pop-off” valve indicates crimp completion
- Open "C" head, rotatable 350 degrees
- 2-stage hydraulic system: rapid advance double action handle and power stroke
- Automatic retraction when operation is complete
- Manual retraction operation if needed
- Environmentally-friendly hydraulic oil, biodegradable
Specifications
| Application | Crimps Panduit Copper and Aluminum compression connectors using Panduit Crimping Dies. |
|---|---|
| Crimp Profile | Circumferential |
| Tool Type | Die Type |
| Base Material | Steel |
| Compatible Connector | CD-920 and CD-930 Dies |
| Insulated Tool Head | No |
| Jaw Opening Width (In.) | 1.65 |
| Jaw Opening Width (mm) | 42 |
| Crimp Force (ton) | 12 |
| Crimp Head Rotation (°) | 350 |
| Overall Length (In.) | 22.1 |
| Overall Length (mm) | 560 |
| Overall Width (In.) | 2.9 |
| Overall Width (mm) | 74 |
| Overall Height (In.) | 8.5 |
| Overall Height (mm) | 217 |
| Weight (Kg) | 5.9 |
| Weight (lb) | 13 |
| For Use With | CD-920, CD-930 |
| Includes | (1) Steel Tool Case with Crimp Die Storage |
| Product Type | Hand Crimp Tool |
